Continuous water softener, incorporated (ATTENTION: connection to cold water).
Height of plates load Ø 365mm (height glasses 325 mm).
From 30 to 20 baskets/hour, PLD cycle 120”, 180”, continuously and „Sanitisation”.
3 phases: wash, unload, rinse.
Standard discharge pump.
Standard rinse pump (atmospheric boiler).
Realization entirely in stainless steel AISI 304.
Rotating washing and rinsing arms (upper and lower) (made of composite material).
Self-cleaning nozzles.
Tank (20 lt – 2,1 kW) with rounded edges, „deep-drawn” bottom.
Stamped basket slides, no roughness and no limestone incrustation.
Integral” vat filter (made of composit material).
Patented” pump filter to keep the washing water longer and at the right temperature.
Stamped double-walled door, removable door seal, stamped handle.
Adjustable cylinders.
Removable control panel for easy after-sales service.
Automatic water discharge function integrated in the control panel (no need to remove the bung manually).
Automatic filling of the tank.
Non-return valve.
Hot water rinse (water consumption per cycle 2.4 liters), stainless steel boiler (6 lt – 4.9 kW).
Possibility to regulate the temperature of the tank and the boiler.
High efficiency washing pump (double flow) guaranteeing significant energy savings.
Microswitch to stop the cycle when the door is opened.
Safety thermostat. Included: 2 baskets, 1 cup, water connection and drain hoses.
PLUS:
„Peristaltic” dispenser of rinse product and „peristaltic” liquid detergent dispenser supplied as standard.
CSD Digital control panel (soft touch).
EED energy saver.
TCD Device which permits to rinse at 85°C.
DRD Accelerated preheating phase.
DID Auto diagnostic in case of failure.
ADD Temperature display of the tank and boiler (HACCP standards).
DDD partial tank emptying, bottom discharge of the tank.
CID Door with automatic closure „soft contact” (partial opening for steam removal).
RGD Rinse at constant temperature, stable pressure.
BDT „Break tank” anti-pollution device AB type.
CAD self-cleaning cycle (100% automatic).
NB: The machines are guaranteed for use with „osmosis” water.
ATTENTION : second choice item.
